PoE and Ethernet with very long range

Coaxial cables are characterized by low attenuation, which allows data connections with a long range.

Telephone cables have higher attenuation, this limits possible cable length. To increase it, G.hn technology provides for MIMO (4-wire) operation in addition to SISO (2-wire). In this case two wire pairs (2 data channels each 2-100MHz) are used instead of one wire pair (1 channel 2-200MHz).

Our master/client modem sets for telephone cables support MIMO operation and enable Ethernet connections with a range of several hundred meters.

Power can also be transmitted via the data line.

The G4202TCP-RPF Master Modem is powered by a USB-C Power Delivery 3.0 adapter and supplies power to the G4202TCP client and connected end devices via the telephone or coaxial cable.


Note. Multiple parallel connections via telephone cable are possible with our master switches. They offer automatic vectoring, also with PoE.

Master/Client Sets for phone cable

G4201TM M/C Set

Price for 2 devices:

256.00  (incl. VAT) Add to basket

data sheet
manual
  • 1 * G.hn Wave2 SISO/MIMO Port (RJ11)
  • 1 * 10/100/1000BaseT Port (RJ45)

Also available at eBay or Amazon

G4202T M/C Set

Price for 2 devices:

270.00  (incl. VAT) Add to basket

data sheet
manual
  • 1 * G.hn Wave2 SISO/MIMO Port (RJ45)
  • 1 * analog phone (RJ45)
  • 2 * 10/100/1000BaseT Port (RJ45)

Also available at eBay or Amazon



Master/Client PoE+ Sets for telephone-/coax cable

G4202TCP-RPF + G4202TCP
M/C Set for phone cable

Price for 2 devices:

495.00  (incl. VAT) Add to basket

data sheet G4202TCP-RPF
data sheet G4202TCP
manual
  • 1 * G.hn Wave2 SISO/MIMO Port (RJ45)
  • 2 * 10/100/1000BaseT Port with 30W PoE+ (RJ45)
  • G4202TCP-RPF: 30W power delivery to G.hn Port
  • G4202TCP: power supply via G.hn port
  • IP30 casing, temperature range -10 – 45°C

Incl. 65W USB-C PD power adaptor

G4202TCP-RPF + G4202TCP
M/C Set for coaxial cable

Price for 2 devices:

495.00  (incl. VAT) Add to basket

data sheet G4202TCP-RPF
data sheet G4202TCP
manual
  • 1 * G.hn Wave2 Port (F-Connector)
  • 2 * 10/100/1000BaseT Port with 30W PoE+ (RJ45)
  • G4202TCP-RPF: 30W power delivery to G.hn Port
  • G4202TCP: power supply via G.hn port
  • IP30 casing, temperature range -10 – 45°C

Incl. 65W USB-C PD power adaptor
